公开 SD90-5 Bulldozer Introduction

and developed in response to the market demands adopt the

international advanced technology，This product is applicable for the earthworks for large projects such as mines and water conservancy projects,even more severe working environment ,Can greatly improve the productivity, reduce the operation cost.SD90-5 is currently the largest domestic production of horsepower bulldozer.
basic configuration: air conditioning, ROPS, hexahedron cab, semi-U-blade, single-shank ripper, ripper pull pin device, 710mm track shoes, temperature-controlled fan.

oil consumption is 90L each hour, the using capacity of

fuel oil tank is 1,638L, and the oil filling interval is 18 hours;

2） Max dozing capacity：
In case of calculating based on transportation distance of 40m, the maximum earth moving productivity of SD90-5 may reach 4,339m3/h;

design, and its engine, double transmission, final drive and trolley

assembly all can be dismantled independently, with advantages of advanced structure, strong power, convenient dismantling and simple repair.

shape, direct-injection, electronic control,diesel engine
equipped with advanced MCRS(Modular Common Rail

System )
strong power and low fuel consumption.
rated speed ： 708 kW/2100 rpm
Max Torque：4191 Nm/1300 rpm
the emission standard meet the European stageⅡrequirement。

the transform between Different transmission modes Hydraulic/Mechanical come true, improves

the transmission efficiency,reduce energy consumption of the bulldozer by 5%.

lubricative、 three speeds forward and three speeds reverse ,hydraulic shift，all

produced by shantui 。

bevel gear ；
Steering clutch：oil-type、 tighten by pressured multi-springs、separated hydraulically、Normally-closed

；
Steering Breaking：oil-type、 tighten by pressured multi-springs、separated hydraulically、Normally-closed ；
all above three parts are adopts the modular design ， with parking brake function able to avoid Anti-running System。

三、structure characteristic

Center Transmission&Steering clutch、breaking

planetary gear 、 splash lubricating 。Bolts、 Gear all are high

Hardness，Wear-resistance Materials;，high reliability、 long service life。

ground、floating travel，could strong the tractive power in Complex Road Condition

。track roller、carrier roller、track shoes all adopt imported parts，high reliability、Wear-resistance

back flush;
fast-response，automatic control the Rotating Speed of Fan according to

temperature.
Working Parameters could Settings ， improve fuel economy，Energy saving 10%.

，good Stablity， labor-saving 。

lever on the drivers left side. ；
(2) Engine operation：electronic throttle

and Decelerator Pedal， throttle on the left side of driver，Decelerator Pedal on the right of drivers foot；
(3) Brake pedal：single brake pedal control， on right ahead of driver，；
(4) Work equipment operation：on the right side of driver，the blade control on the front of driver（Integrated floating and double-dump switch）ripper control on the behind side。with accumulator，could lower the blade and ripper when TURN THE IGNITION OFF.

display，fault information，electronically monitored&overload alarm to mainly parts operations such as

Oil temperature、Fuel level、Water temperature、water level .show and Diagnosis of Automation System Error。With GPS，cameras Back and forth， high-brightness HID，adopts imported key electrical parts，high reabiltiy

rang；
2）sealed well、low noise，about 89dB；
3）imported seat，could rotate 15°，good comfortability；
4）big power Air

Conditioning,， good cooling effect
5）human choosable confugurations，such as The cup holder、 ash tray、 storage box、radion and so on.
6）safty protection，ROPS/FOPS cab

degrees,raising the driving′s safety and passing ability.

blade angle and the soil effective depth; Realization of blade

pitch, Ascension, down, left and right, floating movements.

machine frame by pin,， simple structure，Easy to Install， adopt heavy

duty ripper shank and tooth tips。

data
The main technical performance reached the international level, cost-effective.

solid coefficient
