TPMSPressure-Sensor Based TPMS（shorten for:PSB TPMS, or directness type TPMS）,namely this system monitors tyre pressure by pressure sensor mounted inner tyre thus to display information or warning.TPMS Type

Слайды и текст этой презентации

Слайд 1TPMS Introduction

Слайд 2TPMS
Pressure-Sensor Based TPMS（shorten for:PSB TPMS, or directness type TPMS）,namely this

system monitors tyre pressure by pressure sensor mounted inner tyre

thus to display information or warning.

TPMS Type

TPMSPressure-Sensor Based TPMS（shorten for:PSB TPMS, or directness type TPMS）,namely this system monitors tyre pressure by pressure sensor

Слайд 3 When vehicle speed exceeds 20Km/h,type

pressure sensor begins to work. When vehicle stops for 10

minutes, sensor will entre “sleep”mode for power saving.

Working principle

When vehicle speed exceeds 20Km/h,type pressure sensor begins to work. When vehicle

Слайд 4Schematic Diagram

Слайд 5Circuit Diagram
Sensor 1
Sensor 2
Sensor 3
Sensor 4
ground
Rear mirror
ground
power
Diagnosis interface

Слайд 6● Warning Function
► tyre pressure low：25 ％ lower

than standard value
► tyre pressure high: 25 ％

higher than standard value
► fast air leakage: pressure reduces 20kPa in 12s
► over high temperature：when >75˚C
►signal lost：when receiver not receive signal, showing“ ”
●Other Function：
► sensor battery voltage low or stop working, remind user to replace sensor
►LIN line and power line self diagnosis with code.

Attn: standard value is 230kPa when production.

System Function

● Warning Function ► tyre pressure low：25 ％ lower than standard value ► tyre pressure

Слайд 7Tyre pressure sensor
Pressure receiver
Rear mirror
System Component

Слайд 8 air valve bonnet
Rubber washer
bolt
Tyre pressure monitor emitter
The sensor is

mounted inside each wheel to monitor tyre pressure and temperature,

then send signal to tyre pressure receiver through RF

Tyre Pressure sensor

air valve nut

air valve bonnetRubber washerboltTyre pressure monitor emitterThe sensor is mounted inside each wheel to monitor tyre

Слайд 9Location: don’t forget tyre balance operationg before mounting

Слайд 10Sensor Mount
① screw down nut, then mount air valve nozzle

through wheel hub hole
② screw up nut, then tighten with

torque 3.8N.m（±0.3）by sleeve

Sensor Mount① screw down nut, then mount air valve nozzle through wheel hub hole② screw up nut,

Слайд 11After mount, do tyre balance operation.

Слайд 12receiver
Receiver Location

Слайд 13Ⅰ. TPMS Initialization Operation Guide
Ⅱ. Replace tyre pressure sensor
Ⅲ. Tyre

rotation
Ⅳ. Lin bus self-diagnosis function
TPMS Maintenance

Слайд 14TPMS Program Tool
DC-9V
BMG TPMS Program Tool
MODEL:3641130-K80
INPUT:DC 9V

434MHz
SN:CHADXXXXXXXXX
Laser print

Слайд 15TPMS Program Tool
Tyre position
Enter
Tyre position
indicator
Function
indicator
Function
button
switch
Parameter：
1.dimension： 125×60mm
2. Operating

Tem:-20℃~70 ℃
3. LF frequency: 125KHz±2KHz
4. RF frequency: 433.92MHz±100KHz
5. Input voltage:9V
6.

Working current: <3mA
7.LF spring distance: L<0.5m
8.RF spring distance :L<2.0m

TPMS Program ToolTyre positionEnterTyre position indicatorFunction indicatorFunction buttonswitchParameter：1.dimension： 125×60mm2. Operating Tem:-20℃~70 ℃3. LF frequency: 125KHz±2KHz4. RF frequency:

Слайд 16Function Button
★
★
★

Слайд 17Initialization ( for user who add the system after bought

can use this function )
ATTN: before initialization

operation, please connect power on TPMS, and with ignition key at “ON” gear
1.1 after mounting battery, power on TPMS program tool, system enters self-checking process, all indicator lamps light on, then off, initialization indicator lights on.

Ⅰ. TPMS Initialization Operation Guide

Initialization ( for user who add the system after bought can use this function )

Слайд 181.2 put TPMS program tool close to tyre valve nib

within 50 cm to set sensor to be registered, press

down corresponding tyre position button on program tool like “FL”, “FR”, then tyre position lamp will flash which means it’s waiting for signal from sensor as showed by right figure.
After register succeeds, tyre position lamp will keep on; TPMS program tool will cancel spring if not receiving sensor signal in 10s.

1.2 put TPMS program tool close to tyre valve nib within 50 cm to set sensor to

Слайд 191.3 then register the other tyre position, of course, the

lamps will keep on after register.
1.4 after 4 tyre position

1.3 then register the other tyre position, of course, the lamps will keep on after register.1.4 after

Слайд 201.5 after 4 tyre indicating lamps light on, put TPMS

program tool close to the receiver locating under driver seat

(below figure) within 50cm, press down “ENTER” button, then all 4 tyre position lamp will flash in circle that sending out signals from registered sensor to receiver for saving.

receiver

Слайд 21Receiver

Слайд 221.6 then there will be “SET” displayed in rear mirror,

which means initialization successful as showed by below

1.6 then there will be “SET” displayed in rear mirror, which means initialization successful as showed by

Слайд 231.7 press “SET” button in the rear mirror with 30s

as confirmation, then enter tyre pressure status display in circle,

each interface will be shown for 3s as below figure.
1.8 after register successful, ID information memorized in TPMS program tool could be eliminated by pressing down “ENTER” button, then prepare for next register operation; also ID information memorized in TPMS program tool will be eliminated if not press down “ENTRE” button in 5s.

Pressure display interface

1.7 press “SET” button in the rear mirror with 30s as confirmation, then enter tyre pressure status

Слайд 242. Replace sensor funciton
It’s used for replacing damaged or malfunction

sensor.
2.1 example: replace sensor for tyre FL. Replace malfunction

sensor with new part.
2.2 press “replace sensor” button, function lamp will light on as right figure

ATTN: before operation, ensure TPMS system power on and ignition switched to on gear

Ⅱ. Replace tyre pressure sensor

2. Replace sensor funcitonIt’s used for replacing damaged or malfunction sensor. 2.1 example: replace sensor for tyre

Слайд 252.3 put TPMS program tool close to tyre valve nib

within 50 cm, then press down corresponding tyre position button

on program tool like “FL”, “FR”, then tyre position lamp will flash which means it’s waiting for signal from sensor, tyre position lamp will keep on as showed by right figure.

2.3 put TPMS program tool close to tyre valve nib within 50 cm, then press down corresponding

Слайд 262.4 put TPMS program tool close to the receiver locating

under driver seat within 50cm, press down “ENTER” button, then

all 4 tyre position lamps will flash in sequence that sending out ID signals from sensor to be replaced to receiver for saving, after that there will be “ SET” displayed on rear mirror which means operation ok.
2.5 press “SET” button in the rear mirror with 30s as confirmation, then enter tyre pressure status display in circle, as below figure.

“SET” button

2.4 put TPMS program tool close to the receiver locating under driver seat within 50cm, press down

Слайд 273. Tyre rotation
there is no need to remove tyre

pressure mounted inside tyre when operating,only with TPMS program tool

to adjust and reset orignal emitter position that system could work normally.

Ⅲ. Tyre rotation

3. Tyre rotation there is no need to remove tyre pressure mounted inside tyre when operating,only with

Слайд 28Operation Steps:
3.1 switch on ignition, power on TPMS program tool,

press down tyre rotation function button, indicator will light on.

Operation Steps:3.1 switch on ignition, power on TPMS program tool, press down tyre rotation function button, indicator

Слайд 293.2 press down tyre position button in sequence, then lamps

will be on which means this two tyres will be

exchanged, pressing tyre position button could cancel the funciton as right figure.

3.2 press down tyre position button in sequence, then lamps will be on which means this two

Слайд 303.3After selecting tyres to be exchanged each other, put TPMS

program tool close to the receiver locating under driver seat

within 50cm, press down “ENTER” button, then all 4 tyre position lamps will flash in sequence that sending out ID signals from sensor to be replaced to receiver for saving,

receiver

Слайд 313.4 there will be “SET” showed by rear mirror after

receiver receiving signal
3.5 press “SET” button in the rear

mirror in 30s as confirmation, then enter tyre pressure status display in circle, as below figure.
ATTN: during setting process, if “SET” button in the rear mirror not be pressed down within 30s, operation failure which means it should done from beginning.

“SET”确认键

3.4 there will be “SET” showed by rear mirror after receiver receiving signal 3.5 press “SET” button

Слайд 32 in case when receiver and Lin line or

IGN power line malfunction, rear mirror will entre into self

diagnosis function

All 4 tyre indicators show red color and flash for 5s（0.5S off, 0.5S on）, buzzer warns 5 times （sound 0.5S，silence 0.5S）tyre pressure warning sign ” ” and malfunction code will come on.

Ⅳ. Lin bus self-diagnosis function
